High Pressure Packaged Pump System

High Pressure Packaged Pump System

DANATIVARA presents its High Pressure Packaged Pump System, meticulously crafted to handle the pumping of higher viscosity hydrocarbons (10 centistokes) at elevated discharge pressures. This comprehensive system encompasses screw pump(s), electric motor(s), suction/discharge piping, valving, instrumentation, controls, and is strategically designed to curtail the need for on-site assembly.

Advantages:
– Unified Responsibility: Single-source accountability streamlines management.
– Modular Efficiency: Pre-packaged modular design outperforms component-based site-built systems, resulting in reduced overall project costs.
– Accelerated Deployment: Minimized field assembly time translates to quicker project delivery schedules.
– Thorough Pre-Shipment Testing: Comprehensive system function testing is conducted before shipping.
– 24/7 Customer Support

Adherence to Industry Standards:
– Vessel Compliance: Vessels are ASME Section VIII code stamped and National Board Registered.
– Piping Standards: Piping design aligns with ANSI B31.1/ANSI B31.3.
– Pipe Fabrication: Pipe fabrication adheres to ASME Section IX.
– Structural Integrity: Structural steel assembly is designed to meet AWS D1.1 specifications.

Standard Inclusions:
– Advanced Screw Pumps: API 676 Horizontal Double or Triple Screw Pumps.
– Versatile Pump Casings: Pump casing materials range from Cast Iron to Carbon Steel.
– Motor Enclosure Variants: Available choices include WP-II, TEFC (Totally Enclosed Fan-Cooled), TEAAC (Totally Enclosed Air-to-Air Cooled), or XP (Explosion-Proof) Electric Motor Enclosures.
– Motor Voltage Selection: Choose between 460 Volt or 2300/4160 Volt motor voltage.
– Comprehensive Instrumentation: Full pump/motor instrumentation includes Vibration, Temperature, Flow & Pressure Monitoring.
– Duplex Pump Configuration: Offers 100% standby capacity.
– Sturdy Base Design: Rigid structural steel base with curbed perimeter and drainage to minimize environmental impact.
– Piping Integrity Assurance: Hydrotesting guarantees the integrity of all piping.
– Robust Coating: High-quality industrial coating system ensures long-lasting durability.

Optional Additions:
– Electrical Enclosures: All NEMA or IEC rated enclosures and components for Class 1, Div. 1 or Div. 2 electrical areas.
– User Interface: Panel view operator interface for enhanced user interaction.
– Advanced Control System: Microprocessor controller with integrated control software to monitor critical functions and provide comprehensive system control.
– Stringent Testing: Complete string test of the package before deployment.
– Flexible Configurations: Choose from Simplex & Triplex pump setups.

Supplementary Services:
– Nationwide Support Network
– Expert Installation: Installation & supervision services.
– Comprehensive Solutions: Turn-key project execution.
– Flexible Financing: Equipment leasing program.
– Extended Assurance: Extended equipment warranties.
